Alta Labs

Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount

(No reviews yet) Write a Review
SKU:
S8-POE
MPN:
S8-POE
  • Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount
  • Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount
  • Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount
  • Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount
  • Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount
  • Alta S8-POE 8-Port Cloud-Managed Switch with 4 PoE+ Ports | 60W PoE Budget | Desktop or Wall Mount
$149.00

Please contact for availability

Description

The S8‑PoE is a compact switch with eight 10/100/1000 ports, four of which support PoE+. It can be placed on a desktop or mounted on a wall. All of the Alta Labs switches include Bluetooth functionality for seamless device setup.


Power Over Ethernet

Bluetooth Setup

Mobile App

Egress and Ingress Rate Limiting

IGMP Snooping

802.1X Authentication

Network Loop Detection

Site Manager



Mechanical

Dimensions
25.7 x 91 x 180 mm (1 x 3.6 x 7.1")
Weight
.38 kg (.83 lbs)
Material Type
Injection Molded Plastic
Material Finish
Matte
Color
White

Ports

Interface ports
(8) 10/100/1000 Mbps
SFP/SFP+
None
Switching Capacity
16 Gbps
Non‑blocking Throughput
8 Gbps
Forwarding Rate
11.9 Gbps
PoE Budget/Max
60 Watts
PoE Supply
30 Watts per port
Per Port PoE
(4) 802.3at PoE+
Non‑PoE Ports
(4)

LEDS

PoE
Orange
Network
Orange: 10/100 Mbps, Blue: 1000Mbps
SFP/SFP+
None

Hardware

Packet Buffe
4.1 Mbit
Mac Table Size
8 K
Energy Efficient Ethernet
Yes
Management
Factory reset button
Band
2.4 GHz
Bluetooth Version
BLE
Total Power
5 dBm EIRP
Gain
3 dBi

Power

Idle Power Consumption
3.4 Watts
Max Power Consumption w/o PoE
8 Watts
Max Power Consumption Full PoE
68 Watts
Output
PoE+, 54VDC, 0.6A Max
Power Supply
Universal AC, 100 ‑ 240VAC 50‑60Hz External
RJ45 Port Surge Protection
12kV for ESD ‑ contact, 25kV for ESD ‑ Air

Environmental

Mounting
Locking Wallmount
Operating Temperature
‑5 to 50° C (23 to 122° F)
Operating Humidity
10 to 90% Noncondensing
IP Rating
None
EMI Rating
EMI Class‑B with 3dB margin
Cooling Fan
No (Fanless cooling)
Certifications
CE, FCC, IC
