Description
ANTENNA KEY FEATURES
- 19 dBi Directional Gain
- Integrated enclosure
- Mounting for Mikrotik 411, 433, 600, series
- Mounting for Ubiquiti Rocket
- High Quality Construction
- Horizontal or Vertical Polarization
- Heavy-Duty Mounting Elements
- Easy Elevation and Tilt Adjustment
- 5 Years Warranty
- Designed for All Weather Operation
ANTENNA SPECIFICATION
ELECTRICAL PROPERTIES
Frequency range2.4-2.5 GHz
Gain19 dBi
PolarizationLinear. H or V
Beam width horizontal20° @ -3dB
Beam width vertical20° @ -3dB
VSWR<2
Impedance50 ohm
Front to back ratio>35 dB
MECHANICAL PROPERTIES
ConnectorSMA
Windload150 km/h
Mounting pole Φ5.5cm / 2.16"
RoHS CompliantYes
ENCLOSURE PROPERTIES
MaterialUV protected PS
ColourGrey
Outside dimensions386x386x81.5mm / 15.15x15.15x3.2"
Weight2.33 kg / 5.14 lbs
Temperature range-40 +80°C / -40 +176°F
Lightning protectionDC ground
